Custom-Build - Your Next Dream eBike Developed and Assembled in Sydney; Indicative Price Only
Buy now and pay later with
Designed and Engineered in Australia
Custom-Build Pack including
- Your choice of fork / Yari or ZEB is our recommendation
- Your choice of fork / Super Deluxe Shock is our recommendation
- Your choice of drop post / X Fusion 150mm Drop post is our recommendation
- Front Light wired into the battery included
- Additional Chain guide included
- Price shown is only indicative. Final Price is to be confirmed individually. Please contact us.
48V/1000W Power Performance
One of the hardest design challenge was to integrate the 700Wh battery while keeping the bike’s silhouette slim and elegant without looking like on “steroids”. We also applied a new manufacturing technique to smooth out welding marks on the top and give it a carbon-like finish.
48V 700Wh is the standard battery ; together with the BAFANG M510/M600 motor system, the bike is quiet , full of torque yet butter smooth !
whopping 185mm frame travel!
We made our own linkage. One of the original design goals for us was to create a SUV eMTB with the ability to shred hard on the trails and commute comfortably on the roads. It took us 6 months of 3D modelling to finesse the linkage design and tapping out the 184.8mm of rear wheel travel ! This is an industry leading number. Max dingo feels strong, plush and lively
More Info
| Name | Description / VOLITION AU * Specifications are subject to change without notice | |
| FRAME | Designed & Assembled in Australia Volition 29er Aluminium frame; 148mmx12mm Boost rear; 185mm frame travel | |
| FORK | Rockshox Yari 150mm/160mm Travel | |
| SHOCK | Rockshox Air 210mm Super Deluxe / Frame Travel 185mm | |
| STEM | Enduro Style 35mm | |
| HANDLEBAR | Generic Black; 780mm | |
| GRIP | MTB Grips | |
| SADDLE | MTB Saddle | |
| SEATPOST | 31.6mm DropPost | |
| FRONT BRAKE | Shimano 2 PISTON 203MM ROTOR | |
| REAR BRAKE | Shimano 2 PISTON 203MM ROTOR | |
| REAR DERAILLEUR | Shimano 10 spd | |
| SHIFTER | Shimano 10 spd | |
| CASSETTE | Shimano 10 spd | |
| DRIVE | Chain 10 Spds | |
| CHAINRING | 36T eMTB chainring N.W. | |
| CRANKSET | Bafang MTB custom offset, 170mm, alloy | |
| F. WHEEL SET | 29er Boost, Alloy, eMTB Hub, 6 bolt, 110x15mm , p14 spokes, 28 holes, Tubeless Ready | |
| R. WHEEL SET | 29er Boost, Alloy, eMTB Hub, 6 bolt, 148x12mm , p14 spokes, 28 holes; Tubeless ready | |
| FRONT TYRE | Maxxis Minion Tubeless ready ; DHF EXO | |
| REAR TYRE | Maxxis Minion Tubeless ready ; DHR EXO | |
| INNER TUBES | Schrader Style | |
| – | ||
| MOTOR | Bafang M600, 120Nm of Torque. Top Speed 45Kmh. Or Bafang M510 | |
| THROTTLE | Yes. Installed. Left Hand Thumb Throttle with the M600 system | |
| UI/DISPLAY UNIT | Bafang CAN DISPLAYS | |
| ANTI THEFT | None | |
| BATTERY & KEYS | 48V 700Wh Samsung Semi-Integrated, keys operated lock, on-board charging port | |
| CHARGER | 4.5 Hour Charger | |
| F. LIGHT | Included. | |
| R. LIGHTs | Avail for purchase Contact us | |
| Kick Stand | Avail for purchase Contact us | |
| PEDALS | included. | |
| PANNIER RACK | Avail for purchase Contact us | |
| MUD FENDERS | Avail for purchase | |
| FREE TOOL | Included. | |
| BOX SIZE | 162cm x 30cm x 87cm ; 35Kg Box Weight. Bike Weight around 25kg |
|
| NOTE | It is the customer’s responsibility to be aware of ebike regulations in Australia ! |
MAX (last generation) This new generation will be even more awesome!)
